項目 |
規格 |
 |
| 電源 |
100-240 V AC, 50/60 Hz |
|
|
| 電力消耗 |
180
W (3 W in standby mode with fan stopped) |
|
|
| 光學系統 |
Dichroic mirror separation / prism synthesis system |
|
|
|
LCD面板 |
4:3
aspect ratio |
|
|
| 面板尺寸 |
0.6”
(15.24 mm) diagonal |
|
|
| 成像模式 |
Transparent LCD panel (x 3, R/G/B) |
|
|
| 畫素 |
480,000 (800x600) x 3, total of 1,440,000 pixels |
|
|
| 鏡頭 |
Manual zoom (1:1-1:1.2), manual focus,
F 1.7-1.8, f 17.0-20.4mm |
|
|
| 燈泡 |
130
W UHMTM lamp |
|
|
| 色彩 |
Full
color (16,777,216 colors) |
|
|
| 亮度 |
1,500 lumens |
|
|
|
Uniformity |
90% |
|
|
| 對比
|
400:1 (full on/full off) |
|
|
|
Resolution-RGB |
800x600 pixels (1,600 x 1,200 pixels with
compression) |
|
|
|
Resolution-Video |
600
TV lines (horizontal resolution) |
|
|
|
掃描速率-RGB |
Horizontal: 15-91 kHz, Vertical: 50-85Hz |
|
|
|
掃描速率-YPвPR |
480i(525i),576i(625i),480p(525p),576p(625p),
720p(750p),1080i(1125i),1080i(1125i) |
|
|
| 投射尺寸 |
965
– 7,620 mm (38 – 300 inches) diagonally |
|
|
| 投射距離 |
1.0m
– 9.9m (3’ 3” – 32’ 6”) |
|
|
| 梯形修正 |
垂直±30° |
|
|
| 螢幕選單 |
可選擇文字：英、法、德、西、義、瑞典、西、挪、丹麥、葡、波蘭、匈、捷等…(根據不同國家與地區而有不同的修正。) |
|
|
| 安裝
|
懸掛/桌面，前投/後投(由螢幕選單) |
|
|
[介面端子]
PC IN |
D-sub HD 15-pin x 1 (accepts RGB/YPBPR signal) |
|
|
|
VIDEO IN |
RCA
pin x 1 |
|
|
|
S-VIDEO IN |
Mini
DIN 4-pin x 1 |
|
|
|
AUDIO IN |
RCA
(L, R) x 1 |
|
|
|
SD記憶卡插槽 |
For
SD memory card x 1 |
|
|
| 機殼材質
|
Moulded plastic (ABS/PC) |
|
|
| 外型尺寸 |
234x65x188mm
(9-3/16” x2-17/32” x7-3/8”) |
|
|
| 重量 |
1.3kg (2.9 lbs.) |
|
|
| 操作環境 |
溫度
0°-40℃ (32°-104℉) |
|
|
|
遙控器-電源供應 |
3 V
DC (button battery x 1) |
|
|
|
遙控器-操作範圍 |
Approx. 7 m (23 feet) when operated from directly in
front of the single receptor |
|
|
| 標準配備
|
電源線、卡片式遙控器、遙控器電池、RGB Cable、軟體光碟 |
|
|
| 選購配備
|
ET-LAP1 Replacement lamp unit |
SD記憶卡直接投影功能.jpg)
您會發現PT-P1SD容易攜帶，因為它是全世界最輕巧的機種*5，它僅僅只有1.3公斤重，尺寸長約23.4公分，寬約18.8公分，高約6.5公分。比一張A4的紙張或是信紙還要小上30%左右。這樣的大小足以放入袋子或是公事包中，攜帶方便*6。
